- Part number: J350SM-0405-04
- Material: iglidur® J350
- Shape: Sleeve bearings
- Dimensions:
- d1 4 mm
- d2 5.5 mm
- b1 4 mm
- Adjust dimension
- Manufacturing method: Injection moulding
- Service life:
- Good wear resistance at room temperature
- Very good wear resistance at medium temperatures
- Good wear resistance at high temperatures
- Excellent coefficient of friction
- Very low moisture absorption
- Good wear resistance under water
- High media resistance
- Resistant to high loads (>60N/mm²)
- Mould resistant according to DIN EN ISO 846
iglidur® J350 | Endurance runner with high dimensional stability at temperature - applicable with many shafts and load collectives
A superior material for rotational applications - and that on many different steel shafts: The service life of iglidur® J350 can often be multiplied at loads between 2MPa and 50MPa. In addition, the high temperature resistance makes it a very versatile material.
Typical applications
- Vending machinery
- Automotive
- Glass industry
- Machine tools
When to use it?
- When a wear-resistant material for rotational movement at medium and high loads is required
- When a cost-effective material is required for use at high temperatures
- When press-fit up to +150°C is necessary
- When high wear resistance is required at high loads
- When the material is exposed to shock loading
When not to use it?
- When continuous operating temperatures are higher than +180°C
- When the lowest friction is required
- When a cost-effective, low-friction mterial is sought
- At high peripheral speeds
Unsure if it fits?
